FORTHING T1 PRO RHD
INTERIOR
MODELS PARAMETERS
| FUNCTION | DETAILED PRODUCT DEFINITION |
| |
| DRIVE LINE | |||
| Front Wheel Drive FWD | S | ||
| E-MOTOR / PERFORMANCE | |||
| 7in1 52 kW - 0-50km/h : tbc - 0-100km/h : tbc - 80-120 km/h : tbc | S | ||
| - 52 kW | S | ||
| - 75 kW | O | ||
| - 130km/h (at least display) | S | ||
| Hill start | - 20% slope take off with 4 people @~60%USOC | S | |
| Hill climb | - 60km/h on 4% slope with 4 people @~60%USOC - 30km/h on 12% slope with 4 people @~60%USOC | S | |
| BATTERY / RANGE | |||
| LFP | S | ||
| 345 V | S | ||
| 220 km WLTP w/o ecomode | S | ||
| Adjustable - B (brake) position on gearshift selector | S | ||
| 8y / 160 kkm with 75% SOH - 10y without sudden death | S | ||
| CHARGE | |||
| AC charger | AC 6,6kW (100% SOC in 4h56) | S | |
| DC charger | DC 30kW (80% SOC in 51min) - RE2 : option possible only if the max power engine option is elected - Car sharing & cargo : mandatory in case of max power engine option | O | |
| FRONT SEAT BELTS | |||
| 3-point with height adjustment | S | ||
| Driver | Crash locking tongue (CLT) | S | |
| Retractor with load limiter (6kN) | - | ||
| Retractor with load limiter (4 kN) | S | ||
| Pyrotechnic pretensioner | S | ||
| SBR (Seat belt reminder) - Visual & audio warnings | S | ||
| Passenger | Crash locking tongue (CLT) | S | |
| Retractor with load limiter (6kN) | - | ||
| Retractor with load limiter (4 kN) | S | ||
| Pyrotechnic pretensioner | S | ||
| SBR (Seat belt reminder) - Visual & audio warnings | S | ||
| Colour | Black | S | |
| REAR SEAT BELTS | |||
| 3-points | S | ||
| Side places | Retractor | S | |
| Load limiter | S | ||
| Pyrotechnic pretensioner | S | ||
| SBR (Seat belt reminder) | S | ||
| Colour | Black | S | |
| AIRBAGS | |||
| Driver airbag | S | ||
| Front passenger airbag | WITHOUT passenger airbag deactivation | _ | |
| WITH passenger airbag deactivation (physical switch) | S | ||
| Side airbags (chest / thorax) | S | ||
| Curtain airbags (front) | S | ||
| BRAKE TYPE | |||
| Front discs | Low steel | S | |
| Painted discs (for Perceived Quality / PQ / Anti rust perception) | _ | ||
| Rear drum | S | ||
| CONTROLED SYSTEMS | |||
| Brake booster (8'') | S | ||
| Brake booster (9'') | S | ||
| ABS (Anti-lock Braking System) | - with EBD/EBV - with activated ABS indicator in the instrument cluster | S | |
| BAS (Braking Assist System) / AFU (Assistance Freinage d'Urgence) | S | ||
| HSA (Hill Start Assist) | S | ||
| ESC (Electronic Stability Control) / ESP | - With associated indicator in the instrument cluster - With ESP inhibition switch or cluster MMI sub-menu | S | |
| AEBS for GSR2 B - speed range 7 to 125 kph - compatible with ENCAP protocol, Inter-urban (30-80KPH) / City (10-50KPH) - compatible with AEBS obstacle & moving vehicle which covers > car to car stationary obstacle > car to car moving obstacle > car to car braking - Eu compatible with “Pedestrian and cyclist (compulsory as of 26)” | see sheet 14 | ||
| LKA (Lane Keeping Assist) | see sheet 14 | ||
| LDW (Lane Departure Warning) -> Critère TCS DLIGM1 | see sheet 14 | ||
| Traffic Sign Recognition (TSR) | see sheet 14 | ||
| GSR2/ph2- ISA (Intelligent Speed Assistant) -> Warning in case the applicable speed is exceeded (GSR2) | see sheet 14 | ||
| GSR2/ph2 - DDAW (Driver Drowsiness and Attention Warning) | see sheet 14 | ||
| OPS (Overspeed Prevention) | see sheet 14 | ||
| BODY PAINTING | |||
| Solid colour | S | ||
| Metallic colour | O | ||
| ROOF | |||
| Stamped sheet metal (Normal roof) | S | ||
| FRONT HOOD | |||
| Hood stay rod | S | ||
| SIDE-DOORS | |||
| Front window lifts | Manual windows (LVM) | _ | |
| Power windows with switches backlighted by night located in the center of the dasboard (LVE) | S | ||
| Power window lifts with one-touch up/down and with anti-pinch device (LVI) | _ | ||
| Rear window lifts | Manual windows (LVM) | S | |
| Rear Power Windows with switch backlighted by night located on rear doors (LVE) | _ | ||
| Power window lifts with one-touch up/down and with anti-pinch device (LVI) | _ | ||
| Rear Power Windows inhibition switch by driver (safety / security / child protection) | _ | ||
| TAILGATE MECHANISM & OPENING | |||
| 2 opening gas-stays (compliant with cold countries) | S | ||
| GLAZING TYPE | |||
| Clear glass | _ | ||
| Tinted glass | S | ||
| FRONT GLASS / WINDSHIELD / WINDSCREEN | |||
| Front wiping | RHD: Front wiping system with stop position on passenger side left side | % | |
| Front wiping system with stop position on passenger side | S | ||
| Windscreen wipers : 1 mono wiper arm with panthograh system | S | ||
| Front washing | Water tank std capacity (3 litres approx) - RHD Europe : 1,5L approx (packaging contraint) water tank LATAM 1,5 litres | S | |
| 1 front washer (two jets) | S | ||
| REAR GLASS | |||
| Rear wiping | Rear wiper mono-arm with stop position on passenger side | S | |
| Rear washing | 1 rear washer | S | |
| Defogging / Defrosting (LAC) | With associated indicator, switch (backlighted by night) | S | |
| SIDE MIRRORS (ORVM Outside Rear View Mirror) | |||
| Functionalities | Manual folding forward + backward (both directions) | S | |
| Manual adjustment from outside ("Tip tap" type) | _ | ||
| Manual adjustment from inside | _ | ||
| Electrical adjustment | S | ||
| INSIDE MIRROR (IRVM Inside Rear View Mirror) | |||
| WITH day/night adjustment | S | ||
| PARKING AIDS | |||
| Rear parking sensors (Ultrasonic) | S | ||
| Rear View Camera (RVC) (implies digital display and RR parking sensors) | O | ||
| FRONT LIGHTING | |||
| Headlamps new styling | S | ||
| Turning INDICATORS (located into the front lamp unit) | S | ||
| Head Lamp leveller / height adjuster from inside, driver side (easy to reach) | S | ||
| LED Daytime Running Lights (DRL) with new styling - Dim down or turn off when turn indicator is on. | S | ||
| Automatic day/night head lamps | S | ||
| REAR LIGHTING | |||
| Rear FOG lamps | S | ||
| PARKING BRAKE CONSOLE | |||
| Parking brake console | S | ||
| DE-ACTIVATION CONTROL FOR THE FRONT PASSENGER AIRBAG | |||
| Front passenger airbag OFF / ON control, with associated indicator | S | ||
| AMDC cluster 7'' | S | ||
| Speed limiter - speed display | S | ||
| Cruise control- speed display | S | ||
| Outside temperature | S | ||
| Indirect TPMS (Tyre Pressure Monitoring System) | S | ||
| Cruise control / Speed limiter | Speed limiter with dedicated HMI (LV) | S | |
| Cruise control with dedicated HMI (RV) | S | ||
| Speed limiter with buzzer (EuroNCAP specs) | S | ||
| RADIO PRE-EQUIPEMENT | |||
| Power supply wiring (for radio) | + permanent + primary ignition supply - Earth | S | |
| FRONT speakers wiring | S | ||
| Coaxial wiring (for antenna) | Anti-interference | S | |
| Short antenna located on the rear of the roof | S | ||
| MULTIMEDIA / AUDIO SYSTEMS | |||
| Digital display | - CCS Access '- 10'1' touchcreen display - Tuner Analogic + Digital (DAB) - Bluetooth for music & hands free phoning - Wifi Smartphone replication (Android Auto and Apple CarPlay) - MyDaciaone App to be replicable TBC - Push-To-Talk button (physical) - microphone roof mounted - Support for RearView Camera (RVC) - Wi-fi + USB (data exchange + 2A charge) + AUX ports - Energy flows - ON BOARD EV connected services | S | |
| SPEAKERS | |||
| 2 FRONT speakers | Diameter 100mm dual cone located at the dashboard ends | S | |
| SOCKETS | |||
| 12V socket with flip cap | For front passengers, located on console | S | |
| simple USB socket (USB C data + charge) | located on dashboard | S | |
| double USB socket (USB C data + charge) | located below HVAC controls | O | |
| EDR (Event Data Recorder) | S | ||
| Electric Power Steering, with associated failure indicator in the instrument cluster (DAE / EPS) | S | ||
| Tilt Steering column (= height adjustable steering wheel) | S | ||
| STEERING WHEEL | |||
| Safety | Airbag | S | |
| LOCATION | |||
| Std parking brake lever centered between the front seats | S | ||
| 4 kW heater | S | ||
| Manual A/C (with associated controls) | S | ||
| PM2.5 | S | ||
| UPHOLSTERIES / COVERING | |||
| New dual color full fabric seat (see CCM) | S | ||
| HEADRESTS | Foam integrated headrest | S | |
| ADJUSTMENTS | Longitudinal adjustment (manual) | S | |
| Backrest recliner | S | ||
| Resting position of the backrest (sleeping position) | S | ||
| REAR SEATS | |||
| Rear bench with 1:1 foldable and removable backrest | S | ||
| CHILD SEAT ANCHORAGE | Fastening points for 2 ISOFIX child seats (includes ISOFIX labelling on seats) | S | |
| 2 headrests sideways - comma type - height adjustable - removable - when in lower position, must be compatible with backrest folding | S | ||
| TYRES | |||
| Road type 165/65 R15 | S | ||
| Europe 15" Steel wheel - Black painted | S | ||
| Europe: Full plastic cover for E2 version in case of 65hp engine - clipped fitment in 15'' | S | ||
| Tire repair kit (instead of a standard spare wheel) | w box | S | |
FEATURES HIGHLIGHTS
The Dongfeng Forthing T1 Pro is a pure electric SUV offered by Dongfeng Motor. It's marketed as a long-range, new energy vehicle. The T1 Pro is a popular choice in the Chinese market and is known for its good range and value. It's a compact SUV, likely targeting a budget-conscious buyer.
Pure Electric:
The T1 Pro is an electric vehicle (EV), meaning it runs on electricity and has no internal combustion engine.
SUV:
It's classified as a Sport Utility Vehicle, known for its spaciousness and versatility.
Long Range:
One of the key selling points is its claimed long range, suggesting it can travel a significant distance on a single charge.
New Energy Vehicle (NEV):
This categorization highlights its focus on environmentally friendly technology and government incentives for EVs in China.
China-Specific:
The T1 Pro is primarily marketed in the Chinese market and is likely priced competitively within that market.
Dongfeng Motor:
It's manufactured by Dongfeng Motor, a major automotive company in China with a long history.
